Inconel Forged Fittings Manufacturer, Supplier & Exporter

Inconel Forged Fittings | Inconel 625 / 600 Elbow, Tee, Coupling Manufacturer

STAINLESS INDIA stands as a prominent manufacturer, stockist, and international exporter of Inconel Forged Fittings, providing high-quality forged components in Inconel grades 600, 625, 601, and 718.

We manufacture forged fittings in compliance with ASTM B564, ASME B16.11, ANSI, DIN, and EN standards. Our Inconel forged fittings are relied upon for their high-temperature stability, remarkable corrosion resistance, and excellent mechanical strength, even in the most demanding industrial conditions.

What Are Inconel Forged Fittings?

Inconel forged fittings are high-pressure piping components manufactured through the forging process, which involves shaping metal using localized compressive forces. These fittings are crafted from nickel-chromium superalloys to provide maximum structural integrity and leak-proof connections in high-stress environments. Unlike standard fittings, the forged variety offers a refined grain structure, resulting in superior mechanical strength and fatigue resistance. They are essential for high-temperature and high-pressure systems in nuclear power plants, aerospace engines, and offshore oil drilling where safety and durability are non-negotiable.

Forged Range

Types of Inconel Forged Fittings We Manufacture

Forged Elbows
  • 90° & 45° Forged Elbow
  • Socket Weld (SW)
  • Threaded (NPT/BSP)
Tees & Cross
  • Equal & Reducing Tee
  • Forged Cross
  • High Pressure Ratings
Couplings & Unions
  • Full & Half Coupling
  • Forged Pipe Union
  • Reducing Couplings
Plugs & Bushings
  • Hex Head Plug
  • Square Head Plug
  • Forged Bushings
Technical Data

Forged Grades & Standards

Material Category Available Forged Grades
Inconel Forged Fittings High Pressure Superalloys
Inconel 600 Inconel 601 Inconel 625 Inconel 718 Incoloy 800 (H/HT) Incoloy 825
Standards
  • ASTM B564 / ASME SB564
  • ASME B16.11 (Forged)
  • MSS-SP-79, 83, 95, 97
Manufacture
  • Size: 1/8" NB to 4" NB
  • Class: 2000, 3000, 6000, 9000 LBS
  • Type: Socket Weld & Threaded
Certification
  • MTC EN 10204 3.1
  • 100% Radiography Tested
  • NACE MR0175 Compliant
Quality Assurance

Inconel Forged Fittings

Certified Quality

ISO, IBR, PED & CE Certified Manufacturer ensuring 100% compliance with international Inconel forging standards.

Rigorous Testing

In-house PMI, ultrasonic, and corrosion resistance testing specifically for high-nickel Inconel grades.

CNC Precision

Utilizing advanced CNC technology for absolute dimensional accuracy in Socket Weld and Threaded fittings.

Global Logistics

Swift dispatch and specialized export handling for Inconel products to over 40 countries worldwide.

Extensive Stock

Ready-to-ship inventory of Inconel 600, 625, and 718 in 2000#, 3000#, and 6000# pressure ratings.

Competitive Edge

Factory-direct pricing for premium forged alloys combined with rapid project turnaround times.

Common Forged Applications

Oil & Gas Refineries
Chemical Processing
Aerospace Components
Marine Engineering
Power Generation
High-Temp Exchangers

Documents & Compliance

  • Mill Test Certificate (EN 10204 3.1/3.2)
  • Third-Party Inspection (SGS, TUV, DNV)
  • NACE MR0175 / ISO 15156 Compliance
  • PMI, IGC, and Hardness Reports
  • Visual & Dimensional Inspection
  • Raw Material Test Reports

Frequently Asked Questions – Inconel Forged Fittings

Socket Weld fittings are designed for high-pressure piping systems that necessitate permanent welding, whereas threaded fittings are more suitable for low-pressure, non-critical systems and allow for easy disassembly.

Indeed, Inconel 625 is well-suited for seawater and environments rich in chlorides, providing excellent resistance to pitting and crevice corrosion.

Yes. We offer fittings that comply with NACE MR0175 / ISO 15156 standards for use in sour gas (H₂S) environments.

Yes. We supply both Socket Weld and Threaded (NPT/BSP) forged fittings across all Inconel grades including 600, 625, and 718.

Certainly. We produce custom shapes, sizes, and high-pressure fittings according to client specifications and project drawings.

Certainly. We collaborate with SGS, TUV, BV, DNV, and other agencies for inspections as required by our clients.

Type of Inconel Forged Fittings Available

Inconel Forged Fittings Manufacturer Inconel 625 Threaded Elbow Supplier Inconel 600 Socket Weld Fittings Exporter
Inconel Union Manufacturer India ASTM B564 Forged Fittings Inconel Class 3000 Fittings
Nickel Alloy Threaded Fittings High-Pressure Inconel Forged Fittings BSPT Forged Inconel Fittings
NACE Approved Inconel Fittings Inconel 625 Forged Elbow Nickel Alloy Forged Fittings Supplier
Inconel Threaded Fittings Exporter Inconel 625 Forged Fittings Inconel 600 Forged Fittings
Inconel 625 Threaded Fittings Manufacturer Alloy 600 Socket Weld Fittings Supplier Inconel 718 Forged Fittings

Global Export Network

We export to more than 70+ countries:

USA • UK • Germany • Italy • UAE • Saudi Arabia • Qatar • Oman • Kuwait • Singapore • Malaysia • Indonesia • Australia • South Africa • Brazil • Mexico • India

All Shipments Include:
  • Packing List
  • Invoice
  • MTC 3.1 / 3.2
  • Third-Party Inspection (TUV/LR/BV) if required
  • Heat Number Traceability

Request a Quotation Today

Looking for a dependable Inconel Forged Fittings? We respond within 24 hours.
